January 2001/ version 1.4

WMOi3 Integrated Modem

confidential ©

12/61

This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged

without prior written agreement. Ce document est la propriété exlcusive de WAVECOM. Il ne peut

être communiqué ou divulgué à des tiers sans son autorisation préalable.

Note: Interfaces

The integrated modem has a sole 50-pin connector which gathers all the

interface signals in order to facilitate its integration.

It has an integrated SIM card holder as well as a standard RF connector type

MMCX (Miniature Micro Connector)

The concept of the integrated modem has been defined to integrate on a sole

device:

• only one standard easy to find connector (worldwide supplied) gathering

the analog and digital interfaces

• one standard easy to find RF connector. See chapter RF connector page

• one SIM card holder. See chapter SIM interface
